Product Details:
|
| Name: | Marine Weld Pins | Type: | CD Type |
|---|---|---|---|
| Pin Diameter: | 3.0mm, Other Diameter Is Also Available | Length: | 30mm - 250mm |
| Material: | Mild Steel | Surface Treatment: | Zinc Coated , Galvanized |
| Application: | Thermal Insulation,Heat Insulation,Construction,fire Resistance | Fixing Parts: | Self Locking Washers Or Dome Cap Washers |
| Factory: | Yes | Sample: | Available |
| High Light: | Marine CD Weld Pins,12ga CD Weld Pins,Galvanized Steel Marine weld pins |
||
Marine weld pins are mainly used in industries such as ship pipe insulation welding, air conditioning and ventilation pipe insulation welding, and offshore oil platform insulation welding.
Technical data of the Marine Weld Pins
| Specification of the Marine Weld Pins | |||
| Material | Pin diameter | Pin length | Surface treatment |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 38mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 45mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 55mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 60mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 75mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 90mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 114mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 130mm | Zinc coated |
| Mild steel | 10Ga,12Ga,14Ga,3mm in common | 160mm | Zinc coated |
| Note | the pins material/ diameter and length could be customized according to the requimrnets. | ||
| Fixing parts | 38mm self locking washers and 32mm dome cap washers in common , other size washers is also available . | ||
Using method: Use a welding nail gun to directly weld to the equipment when installing the insulation layer on the body. The solder joints are very small, and the temperature effect on the body surface can be ignored.
Marine Weld Pins are divided into two parts consisting of weld pins & washers The weld pins could be mild steel material and stainless steel material . the surface is plated with copper or galvanized, and the lock plates are stamped from galvanized sheets. The product's load-bearing and compressive performance is very good, not easy to deform, moisture-proof, noise-proof and other advantages. The overall effect can be quite good.
We also could provide the Welding machine for installing .
The packing of the Marine Weld Pins
The Marine weld pins usuallly packing with plastic bags +cartons+wooden case /pallet.
It also could be packing according to the customers requirements.
