50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials

50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials
50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials

Large Image :  50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials

Product Details:
Place of Origin: China
Brand Name: HUIHAOCUSTOM
Certification: ISO9001-2015
Model Number: Perforated insulation fixing pins
Payment & Shipping Terms:
Minimum Order Quantity: 10000 sets
Packaging Details: 100 sets / 250 sets / 500 sets per carton + pallet
Delivery Time: 7 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 400000 sets per 30 days

50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials

Description
Name: Perforated Insulation Fixing Pins Company Type: Manufacturer
Base Material: High Hardness Steel Base Size: 2" X 2" (50 X 50mm )
Shank Material: Anneaded Steel Wire / Stainless Steel Wire / Aluminum Wire Pin Diameter: 12 Ga ( 2.7 Mm ) , 3 Mm In Standard
Application: Heating, Ventilation And Air Conditioning (HVAC) Systems Shank Length: 15 MM - 280 MM
High Light:

50 mm perforated insulation pins

,

stainless steel fixing perforated insulation pins

,

attaching materials perforated insulation pins

50mm Stainless Steel Perforated Insulation Fixing Pins Used For Attaching Insulation Materials

Quick details of the 50mm stainless steel perforated insulation fixing pins



Name: 50mm Stainless Steel Perforated Insulation Fixing Pins Used For Attaching Insulation Materials

Factory: Xiangyi Parts

Base Material: stainless steel

Base Size: 50x50mm

Base Thickness: 0.4mm

Pin Diameter: 2.7mm

Pin Length: 50mm

Self locking washers: 30mm



50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 0



Specification details of the perforated insulation fixing pins



Base size in common: 40mmx40mm, 50mmx50mm
Pin diameter in common: 2mm, 2.5mm, 2.7mm, 3mm and 10ga (3.4mm)
Pin length in common: 50mm, 63mm, 90mm, 114mm, 125mm, 175mm, 203mm, 230mm

Surface treatment: zinc coated or copper coated for mild steel material





Material available







Pin material



-mild steel: must be annealed treatment, easy

for bend; zinc coated/copper plated finished

for anti-rust

-aluminum 1100 grade

-annealed stainless steel for specification



Base



Galvanized steel, stainless steel





                                                          Common Size Details



base type



pin diameter



pin length



material thickness



25 mm x 25 mm



1.8 mm , 2.0 mm



20 mm - 114mm



0.4 mm



40 mm x 40 mm



2.5 mm



20 mm -180mm



0.4 mm



50 mm x50 mm



2.7 mm , 3.0mm



50 mm - 280mm



0.4 mm



Applications of the perforated insulation fixing pins



50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 1

1. Wipe surface clean

Perforated insulation hangers must be applied to a clean, dry, non-painted surface.

50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 2

2. Apply adhesive to the bottom of the perforated insulation hangers

Spread adhesive onto the perforated base with a putty knife.

50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 3

3. immediately stick the insulation hangers in place.

Press the hangers into position with a twisting motion to assure an even spread of adhesive.

The adhesive should protrude through the performation & beyond the edges of base.

50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 4 4. Install Insulation
Note: allow adhesive to dry thoroughly before hanging insulation, usually 24-72 hours.
50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 5

5. Secure with washers

Secure insulation in place with a self locking washer and then bend over or clip off the pin



Package of the perforated insulation fixing pins



PIN LENGTH

CARTON SIZE

QTY/CARTON

38MM

41CMX28CMX17CM

1000PCS

50MM-65MM

41CMX28CMX17CM

500PCS

70MM-84MM

30CMX28CMX29CM

500PCS

90MM-120MM

30CMX30CMX30CM

500PCS

130MM-160MM

30CMX30CMX35CM

500PCS

170MM-203MM

30CMX30CMX28CM

250PCS

OTHERS

SUPPORT CUSTOM



50mm Stainless Steel Perforated Insulation Fixing Pins For Attaching Insulation Materials 6



FAQ Of Xiangyi Metal Products CO.,Ltd.



1. Are you manufacture or trader?

  • We are the manufacture and we sell what we make.

2. Do you support product customization?

  • Yes, the material, the size, all could be customizied according to your request.

3. Can you accept small order?

  • Yes, for common size, we could accept small orders.

4. Can i get samples?

  • Yes, for common size, samples for quality confirm is supported in our company.

5. What is your advantages?

  • Competitive price: we sale what we manufacture.
  • Excellent quality: we have rich experience, our products are in line with international standard.
  • Good after-sale service: we offer good after-sale service for each order.
  • Our products are consist in price, quality and delivery service.
