200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork

I'm Online Chat Now

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork
200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork
200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork

Large Image :  200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork

Product Details:
Place of Origin: China
Brand Name: HUIHAOCUSTOM
Certification: ISO9001-2015
Model Number: self-stick insulation hangers
Payment & Shipping Terms:
Minimum Order Quantity: 10000 self stick insulation hangers with 10000 self locking washers
Packaging Details: Inner Plastic Bag+ Outer Carton in standard for self stick insulation hangers
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 380000 sets per 30 days

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork

Description
Name: Self-stick Insulation Hangers Factory Name: Xiangyi Parts
Material: Galvanized Steel Base Type: 50 Mm Square Double Tape
Pin Feature: Soft Wire And Easy Bending Pin Length: 38mm -230mm Is Standard
Application: Fixing Insulation Materials Pin Diameter: 12GA, 3mm
High Light:

200mm self stick insulation hangers

,

hvac ductwork self stick insulation hangers

,

200mm self adhesive insulation hangers

200mm Galvanized Steel Self-stick Insulation Hangers Used For HVAC Ductwork

Quick Details Of The 200mm Galvanized Steel Self-stick insulation hangers

Self-stick insulation hangers are widely used for fiberglass duct wrap on sheet metal

HVAC ductwork.

The insulation hangers could fasten the insulation materials to sheet metal quickly and easily.

There is a foam adhesive on the bottom of the insulation hangers which will be revealed when

the wax release paper is removed.

Once the insulation material is pierced onto the insulation hangers, a locking washer or a dome

cap washer is needed to hold the insulation material in place.





Factory Hebei Xiangyi Metal Product Co.,Ltd
Name 200mm Galvanized Steel Self-stick Insulation Hangers Used For HVAC Ductwork
Material Galvanized Steel
Base size 50x50mm
Pin diameter 3.0mm
Pin length

200mm



200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 0



Specifications Of The Self-stick Insulation Hangers



Popular sizes of the insulation stick pins

material base size pin diameter pin length fixed parts

pin material:

anneaded steel wire

anneaded stainless steel wire

aluminum wire

base material:

hardness steel

stainless steel

base size:

50x50mm

base thickness:

0.4mm

adhesive thickness:

1mm

base type:

double adhesive

liner:

siliconized paper

2.7mm 38mm

self locking washer

doom cap washer

2.7mm 45mm
2.7mm 55mm
2.7mm 62mm
2.7mm 90mm
2.7mm,3.0mm 114mm
2.7mm,3.0mm 120mm
2.7mm,3.0mm 140mm
2.7mm,3.0mm 160mm
2.7mm,3.0mm 180mm
2.7mm,3.0mm 203mm
2.7mm,3.0mm 230mm



Self locking washers of the insulation stick pins

Type Size Material Ceter hole Picture
round

30mm

32mm

38mm

galvanized steel, stainless steel, aluminum 2mm-5mm 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 1
square

32mmx32mm

29mmx31mm

65mmx65mm

galvanized steel, stainless steel, aluminum

2mm-

5mm

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 2
dome cap

30mm

32mm

38mm

galvanized steel, stainless steel, aluminum 2mm-5mm 200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 3




HEBEI XIANGYI METAL PRODUCT CO.,LTD



HEBEI XIANGYI specializes in the production and operation of various standard and non-standard

insulation fasteners.

Our company established in 2011 and covers an area of more than 13,000 square meters,

with a construction area of more than 9,000 square meters.

We have more than 50 sets of fastener production equipment and perfect testing equipment and

supporting facilities for production, safety and environmental protection.

We have passed the ISO 9001-2015 international quality system certification and have a strict

product quality control system.

HEBEI XIANGYI adheres to the mission of "with first-class management and technology to provide

users with high-quality products, serve our customers with advanced marketing concepts."

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 4



Why choose our HEBEI XIANGYI insulation fasteners?


1.We choose the best quality materials for making insulation fasteners
2.We do copper plating, zinc coated and phosphating pretreatment for the raw material using

drawing machine.
3.We purchase the multi-station cold forging machine to ensure the better mechanical property

of shear connector to match the standard (BS EN ISO13918:2008, AWS D1.1, etc.),

or as per customer's special requirement.
4.We use the automatic riveting machine to install .
5.After rust prevention, XIANGYI insulation fasteners can suitable for long time ship on the sea.
6.Short delivery time because of our reasonable production flow management

200mm Galvanized Steel Self Stick Insulation Hangers For Hvac Ductwork 5
